FRU Name Location Code AIX
Location
Code
Physical
Connection
Logical
Connection
Battery U0.1-P1-V3
Diskette Controller U0.1-P1/D1 01-D1
Diskette Drive
Connector
U0.1-P1-D1 01-D1-00-00 I/O board
connector J28
Keyboard Controller U0.1-P1/K1 01-K1-00
Keyboard Connector U0.1-P1-K1 01-K1-00-00
Mouse Controller U0.1-P1-K11 O1-K1-01
Mouse U0.1-P1-O1 01-K1-01-00
V/S COMM
Connector
U0.1-P1/Q1
JTAG Connector U0.1-P1/Q4 Not used by
AIX
I/O board
connector J9
Parallel Port U0.1-P1/R1 01-R1
Serial Port 1 U0.1-P1/S1 01-S1
Serial Port 2 U0.1-P1/S2 01-S2
Serial Port 3 U0.1-P1/S3 01-S3
Serial Port 4 U0.1-P1/S4 01-S4
RIO Bus Adapter U0.1-P1.1
RIO Port 0
Connector
U0.1-P1.1/Q1
RIO Port 1
Connector
U0.1-P1.1/Q2
PCI Bus Controller 1 U0.1-P1 00-fff7f09000
ISA Bus U0.1-P1 10-80
PCI to PCI Bridge 1 U0.1-P1 10-58 10-5A
10-5C 10-5E
PCI Slot 1 U0.1-P1/I1 10-58
PCI Slot 1 Content U0.1-P1-I1 11-08 thru
11-0F or
12-xx or
13-xx
PCI Slot 2 U0.1-P1/I2 10-5A
PCI Slot 2 Content U0.1-P1-I2 14-08 thru
14-0F or
15-xx or
16-xx
PCI Slot 3 U0.1-P1/I3 10-5C
40 Service Guide
