The following figure shows the configuration of Type 7 PDUs.
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
Power Cord
(Plug Configuration
May Vary)
Type 7 Primary Power Distribution Unit
View of Power
Distribution Unit
Facing Rear of Rack
Circuit Breaker 1
Circuit Breaker 3
Circuit Breaker 2
Circuit Breaker 4
Circuit Breaker 5
View of Power
Distribution Unit
Facing Front of Rack
Chapter 11. Power Cords and Electrical Needs 343
