Multiphase PDUs With Power Cords
The feature codes in the following table have a PDU and a power cord. The power cord has a receptacle
for connection to the PDU plug.
Feature Code for
PDU with Power
Cord
PDU Plug
Power Cord
Receptacle to PDU
Power Cord Plug to
Wall
Standard
Compliance or Type
6173
9173 Except for S70,
S7A, and S80 CEC
Racks. See notes.
IEC 309
380-415 V, 32 A
6174
9174 For S70, S7A,
and S80 Racks. See
Notes.
7178
9178
IEC 309
380-415 V, 16 A
Notes:
1. When an S70, S7A, S80, or S85 CEC is ordered with feature code (FC) 9173, it is supplied with a 16
amp IEC 309 plug. All other racks ordered with FC 9173 are supplied with a 32 amp IEC 309 plug.
2. For power cord information on the Eserver pSeries 690, refer to “Power and Electrical Requirements”
on page 163.
Single Phase PDUs and Power Cords
Separate power cords are available for the PDUs listed in the following table.
PDU
Feature
Code
Power Cord
Feature
Code
PDU Plug
Power Cord
Receptacle to PDU
Power Cord Plug to
Wall
Standard
Compliance or
Type
9171
6171
9177
7177
9823
IEC 309
220 to 240 V, 32 A
9171
6171
9176
7176
9800
9824
9986
NEMA WD-5
L6-30P
250 V, 30 A
9171
6171
9176
7176
9801
9987
R & S 3750
250 V, 30 A
344 Site and Hardware Planning Information
