The Status LEDs (2 and 3 in Figure 1) provide information about the state of the drive. The Ready status LED is green and the
Fault status LED is amber, and (when lit) solid or flashing.
Table 1. Status LED Combinations
Mode SCD Ready LED (green) Fault LED (amber)
Operational Blank On/Off Off
Activity (tape movement) in Operational Mode Blank Flashing Off
Maintenance Solid character Flashing On
Executing Maintenance Selection Flashing character Off (7226 drive feature)
Flashing (eServer)
On
Error Condition Solid character Off Solid/Flashing
Power-On / Reset Initialization random segments Off On
Table 2 lists the conditions of the Status LEDs and Single-character Display (SCD) and provides an explanation of what each
condition means.
Table 2. Meaning of Status LEDs and Single-character Display (SCD)
If the green
Ready Status
LED is...
and the amber
Fault status
LED is...
and the SCD
is...
and the SCD
Dot is...
Meaning
Off Off Off Off The 7226 drive feature drive has no power or is
powered off. The eServer drive will be in this state
when powered up and ready with no tape loaded.
Green/ Solid Off Off Off The 7226 drive feature and eServer drives are
powered on and in an idle state. The 7226 drive
feature drive will be in this state when powered on
even if no tape is loaded. For the eServer drive, this
state also means a tape is loaded
Off Amber/ Solid or
Flashing
Displaying an
error code or
Maintenance
Mode Function
On/Off The drive is displaying error code(s) from the error
code log on the SCD.
Flashing/Off Amber/ Solid Displaying
o
Off/On The Ready Status LED is Flashing while in
maintenance mode for both the 7226 drive feature
and eServer drives. When exiting, the Ready Status
LED is Off on the 7226 drive feature, but is still
Flashing on the eServer.
Off (7226 drive
feature)
Flashing
eServer)
Amber/ Solid Flashing
selected
function
Off/On The 7226 drive feature drive is executing the
selected function while in maintenance mode. The
Ready Status LED on the eServer drive will be
Flashing while executing the selected function.
Off Flashing Amber;
once per second
(7226 drive
feature)
Solid/ Flashing
Amber (eServer)
Displaying error
code
Off An error occurred and the drive or media may
require service, or it may require cleaning. Note the
code on the SCD, then go to Error Codes and
Messages to determine the action that is required.
Off Flashing Amber
(7226 drive
feature)
Solid Amber
(eServer)
Displaying
c
Off The drive needs cleaning.
Off Flashing Amber
(twice per
second)
Off Off The drive detected an error and is performing a
firmware recovery. It will reset automatically.
