IBM InfoPrint 6700 Series

Loading Roll Media
47
7. Thread the media under the media damper and then between the platen
(rubber drive roller) and the printhead.
You can also refer to the arrows on the printer frame or to the label inside
the media cover for media loading instructions.
Media Damper
Printhead
Platen (Rubber
Drive Roller)
Media and
Ribbon Loading
Instruction
Media
