Replacing a RAID adapter battery or flash power module holder
Use this information to replace a RAID adapter battery or flash power module
holder.
About this task
To install a RAID adapter battery or flash power module holder, complete the
following steps:
Procedure
1. Read the safety information that begins on “Safety” on page vii and
“Installation guidelines” on page 33.
2. Turn off the server and peripheral devices and disconnect all power cords and
external devices; then, remove the cover (see “Removing the cover” on page
36).
3. Align the holder and place the holder on the system tray.
Notes:
v There is one holder can be installed in the 3.5-inch models.
v There are two holders can be installed in the 2.5-inch models.
4. Fasten the two screws come with the holder and make sure that the holder is
secured firmly on the system tray.
5. Replacing the cover (see “Replacing the cover” on page 209).
Figure 114. RAID adapter battery or flash power module holder installation
Chapter 6. Removing and replacing components 217
