Icom VHF IC-F50 User Manual

4
2
PANEL DESCRIPTION
2
r SPEAKER-MICROPHONE CONNECTOR [SP MIC]
 Connectstheoptionalspeaker-microphone.(p.54)
[SP MIC] jack cover
NOTE: KEEP the [SP MIC]
jack cover attached to the
transceiver when the speaker-
microphone is not used.
(See page 2 for details)
t DEALER-PROGRAMMABLE KEYS [P0] to [P3]
The desired functions can be assigned independently by your
dealer.
y CH UP AND DOWN KEYS [
]/[ ]
➥
During standby condition, push to select an operating channel.
➥Afterpushing[TXCodeCHSelect],pushtoselectaTXcode
channel.
➥
Afterpushing[DTMFAutodial],pushtoselectaDTMFchannel.
➥Afterpushingandholding[ScanAStart/Stop]/[ScanBStart/
Stop],pushtoselectascangroup.
➥Afterpushing[Digital], push toselect a BIIS code, status
number or SDM.
 *Desiredfunctionscanbeassignedindependentlybyyourdealer.
u TRANSMIT/BUSY INDICATOR
Lights red while transmitting; lights green while receiving a sig-
nal, or when the squelch is open.
i PTT SWITCH [PTT]
Push and hold to transmit; release to receive.

Icom VHF IC-F50 Specifications

General

Brand	Icom
Model	VHF IC-F50
Category	Transceiver
Language	English
