ADS-RR(SR)-VW01-DS
Volkswagen golF r 2012-2013
Automotive Data Solutions Inc. © 2016
6
VEHICLE WIRE REFERENCE CHART
Wire
Description
Connector
Name
Connector
Color
Connector
Type
Position Wire Color Polarity
Wire
Location
CanH A ~ 16 pin 06 Orange/Black (DATA) OBDII connector, under driver side dash
CanL A ~ 16 pin 14 Orange/Brown (DATA) OBDII connector, under driver side dash
Warning: Factory Compass Module
If your vehicle is equipped with a factory compass module and you are installing an aftermarket radio that supplies navigation
information to the MFD of the vehicle, disconnect the factory compass module located under the headliner at the rear of the
vehicle.
