ADS-RR(SR)-SUB01-DS
subaRu wRX without naV 2008-2014
Automotive Data Solutions Inc. © 2017
3
INSTALLATION INSTRUCTIONS
STEP 1
• Unbox the aftermarket radio and locate its main harness.
• Cut the WHITE, GRAY, GREEN and PURPLE RCA tips.
• Connect the wires from aftermarket radio main harness to
the SU1 T-harness and match the wire functions.
• Remove the factory radio.
STEP 2
• Assemble the SU1 T-harness and connect it to the factory
radio harness.
STEP 3
• Connect the PURPLE/WHITE wire from the RED plug of the
SU1 T-harness to the vehicle’s reverse BROWN/YELLOW
wire in the passenger kick panel.
STEP 4
• Plug the OBDII connector into the OBDII of the vehicle,
under driver dash.
STEP 5
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the Data cable to the data port of the aftermarket
radio.
• Insert the Audio cable into the iDatalink 3.5 mm audio jack
of the aftermarket radio.
STEP 6
• Connect all the harnesses to the Maestro RR module then
test your installation.
TROUBLESHOOTING TIPS:
• To reset the module back its factory settings, turn the key
to the OFF position then disconnect all connectors from
the module. Press and hold the module’s programming
button and connect all the connectors back to the module.
Wait, the module’s LED will fl ash RED rapidly (this may
take up to 10 seconds). Release the programming button.
Wait, the LED will turn solid GREEN for 2 seconds.
1
