ADS-RR(SR)-CHR01-DS
Jeep wrangler Jk mt 2007-2018
Automotive Data Solutions Inc. © 2018
6
VEHICLE WIRE REFERENCE CHART
Wire
Description
Connector
Name
Connector
Color
Connector
Type
Position Wire Color Polarity
Wire
Location
CAN2H OBDII ~ 16 pin 06 White/LtBlue (DATA) OBDII connector, under driver side dash
CAN2L OBDII ~ 16 pin 14 White/DkBlue (DATA) OBDII connector, under driver side dash
Reverse light ~ ~ ~ ~ White/Gray (+) Harness in passenger kick panel
