ADS-RR(SR)-VW01B-DS
Volkswagen cc 2016-2018
Automotive Data Solutions Inc. © 2018
3
INSTALLATION INSTRUCTIONS
STEP 1
• Unbox the aftermarket radio and locate its main harness.
• Connect the wires shown on the next page from
aftermarket radio main harness to the VW2 T-harness and
match the wire functions.
STEP 2
• Connect the factory harness to the VW2 T-harness.
STEP 3
• Plug the OBDII connector into the OBDII of the vehicle,
under driver dash.
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the AUX cable to the aftermarket radio (if equipped).
• Plug the backup camera RCA cable to the aftermarket
radio (if equipped).
• Plug the Data cable to the data port of the aftermarket
radio.
• Insert the Audio cable into the iDatalink 3.5 mm audio jack
of the aftermarket radio.
Note: On Pioneer and Alpine radios, the audio cable should
plug into the AUX port.
STEP 5
• Connect all the harnesses to the Maestro RR module then
test your installation.
TROUBLESHOOTING TIPS:
• To reset the module back to its factory settings, turn the
key to the OFF position then disconnect all connectors
from the module. Press and hold the module’s
programming button and connect all the connectors
back to the module. Wait, the module’s LED will fl ash
RED rapidly (this may take up to 10 seconds). Release the
programming button. Wait, the LED will turn solid GREEN
for 2 seconds.
