iDataLink Maestro K150 Install Guide

ADS-RR(SR)-SUB01A-DS
subaRu wRX sti without naV 2008-2014
Automotive Data Solutions Inc. © 2018
5
RADIO WIRE REFERENCE CHART
Wire
Description
Polarity
Wire Color on Maestro
T-Harness
Wire Color on Alpine cable Wire Color on Kenwood cable Wire Color on Pioneer cable
Illumination (+) Orange N/A Orange/White Orange/White
Reverse Light (+) Purple/White Orange/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green
VSS (vehicle speed sensor) (DATA) Pink Green/White N/A Pink
Power Antenna (+) Blue Blue Blue N/A
