iDataLink Maestro K150 Install Guide

ADS-RR(SR)-CHR03M-DS
chRysleR 200 2015-2017
Automotive Data Solutions Inc. © 2018
3
INSTALLATION INSTRUCTIONS
STEP 1
• Unbox the aftermarket radio and locate its main harness.
• Connect the wires shown on the next page from
aftermarket radio main harness to the CH3 T-harness and
match the wire functions.
STEP 2
• Determine if the vehicle has a factory amplifi er. Look for
badges on the radio, door panels and dash that indicate the
presence of an amplifi er (ex: Alpine).
If the vehicle DOES NOT have a factory amplifi er:
• Plug the female GREEN connector to the male GREEN
connector of your CH3 T-harness.
• Plug the female WHITE connector to the male WHITE
connector of your CH3 T-harness.
If the vehicle DOES have a factory amplifi er:
• Plug the female GREEN connector to the male WHITE
connector of your CH3 T-harness.
• Plug the female WHITE connector to the male GREEN
connector of your CH3 T-harness.
• Remove the factory radio.
STEP 3
• Connect the factory harness to the CH3 T-harness.
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the Data cable to the data port of the aftermarket
radio.
• Insert the Audio cable into the iDatalink 3.5 mm audio jack
of the aftermarket radio.
NOTE:
In Pioneer radios: plug Audio cable in auxiliary input of
the radio.
If the vehicle is equipped with parking sensors AND using
an Alpine radio: plug Audio cable in auxiliary input of the
radio.
STEP 5
• Connect all the harnesses to the Maestro RR module then
test your installation.
• If the vehicle is equipped with OEM parking assist, lane
departure, or other safety systems, the ADS-SP1 is
required: Plug the ADS-SP1 the Maestro RR.
If you are not using this speaker, the radio will mute when
the parking assist is active. If you are using this speaker,
the parking assist chimes will play through the external
speaker and the radio will not mute unless the settings
are changed in the radio.
TROUBLESHOOTING TIPS:
• To reset the module back its factory settings, turn the key
to the OFF position then disconnect all connectors from
the module. Press and hold the module’s programming
button and connect all the connectors back to the module.
Wait, the module’s LED will fl ash RED rapidly (this may
take up to 10 seconds). Release the programming button.
Wait, the LED will turn solid GREEN for 2 seconds.
