1.6 Technical Specifications
WAFER-JL-N5105 technical specifications are listed below.
Specification
WAFER-JL-N5105
SoC
Intel® Celeron® N5105 on-board SoC (up to 2.90GHz, Quad-
core, 4M Cache, TDP=10W)
BIOS
AMI UEFI BIOS
Memory
One 260-pin 2933 MHz dual-channel DDR4 SO-DIMM
(system max. 16GB)
Graphics
Intel
®
Gen 11 UHD Graphics
Display Output
Dual independent display
1 x DP 1.4 (up to 4096 x 2160 @60Hz)
1 x HDMI 1.4 (up to 4096 x 2160@30Hz)
Ethernet
3 x Intel® I225V 2.5GbE controller (Colay with I225-LM)
Digital I/O
12-bit digital I/O by 14-pin (2x7) header
Embedded Controller
ITE IT5571E
Watchdog Timer
Software programmable support 1~255 sec. system reset
I/O Interface
Audio Connector
1 x IAUDIO supports IEI AC-KIT-888S Audio Kit (2x5 pin)
Ethernet
3 x RJ-45 GbE port
Serial Ports
2 x RS-232 by 9-pin (1x9 pin, P=1.25) wafer
USB Ports
2 x USB 3.2 Gen 2 on rear I/O
2 x USB 2.0 by 8-pin (2x4 pin, P=2.0) header
Front Panel
1 x Power LED and HDD LED connector by 6-pin (1x6) wafer
1 x Power button connector by 2-pin wafer
1 x Reset button connector by 2-pin wafer
LAN LED
3 x LAN link LED connector by 2-pin header
Fan
1 x System Smart fan connector by 4-pin (1x4) wafer
SMBus/I
2
C
1 x I
2
C connector by 4-pin (1x4) wafer
Storage
1 x SATA 6Gb/s with 5 V SATA power connectors
