IEI Technology WAFER-JL-N5105 User Manual

WAFER-JL-N5105 SBC
Page 44
Pin
Description
Pin
Description
1
VCC
10
VCC
2
USB_DATA0-
11
USB_DATA1-
3
USB_DATA0+
12
USB_ DATA1+
4
GND
13
GND
5
USB3_RX0-
14
USB3_RX1-
6
USB3_RX0+
15
USB3_ RX1+
7
GND
16
GND
8
USB3_TX0-
17
USB3_TX1-
9
USB3_TX0+
18
USB3_TX1+
Table 3-28: USB 3.2 Gen 2 Port Pinouts
3.3.1 External DisplayPort Connector
CN Label:
DP1
CN Type:
External DP connector
CN Location:
See Figure 3-28
CN Pinouts:
See Table 3-29
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DATA_0P
11
GND
2
GND
12
DATA_3N
3
DATA_0N
13
CONFIG1
4
DATA_1P
14
CONFIG2
5
GND
15
AUX_P
6
DATA_1N
16
GND
7
DATA_2P
17
AUX_N
8
GND
18
DP HPD
9
DATA_2N
19
GND
10
DATA_3P
20
DP PWR
Table 3-29: External Display Port Connector Pinouts
