IEI Technology WAFER-JL-N5105 User Manual

WAFER-JL-N5105 SBC
Page 14
Connector
Type
Label
Clear CMOS button
Button
J_CMOS1
AT/ATX power mode setting
3-pin header
J_ATX_AT1
ME override setting jumper
2-pin header
ME_FLASH1
Internal audio connector
10-pin header
AUDIO1
ATX 12V power connector
4-pin Molex
PWR1
Digital I/O connector
14-pin header
DIO1
Fan connector
4-pin header
CPU_FAN1
Power LED & HDD LED connector
6-pin wafer
F_PANEL1
LAN1 link LED connector
2-pin header
JLAN_LED1
LAN2 link LED connector
2-pin header
JLAN_LED2
LAN3 link LED connector
2-pin header
JLAN_LED3
Battery connector
2-pin wafer
BAT2
Power button connector
2-pin wafer
PWR_BTN1
Reset button connector
2-pin wafer
RST_BTN1
RS-232serial port connectors
9-pin wafer
COM1, COM2
SATA 6Gb/s connectors
7-pin SATA connector
SATA1
SATA power connector
2-pin wafer
SATA_PWR1
I2C connector
4-pin wafer
I2C1
Flash SPI ROM connector
6-pin wafer
JSPI1
Internal USB 2.0 connector
8-pin header
USB2_CN1
M.2 B-key slot
M.2 B-key slot
M2_1
M.2 A-key slot
M.2 A-key slot
M2_A1
SIM slot
7-pin SIM holder
SIM1
DDR4 SO-DIMM Socket
260-pin SO-DIMM
DIMM_A1
Table 3-1: Peripheral Interface Connectors
