IEI Technology WAFER-JL-N5105 User Manual

WAFER-JL-N5105 SBC
Page 36
25
N/C
26
GNSS_DISABLE
27
GND
28
N/C
29
PCIE_RXN1
30
UIM_RST
31
PCIE_RXP1
32
UIM_CLK
33
GND
34
UIM_DATA
35
PCIE_TXN1
36
UIM_VCC
37
PCIE_TXP1
38
DEVSLP
39
GND
40
N/C
41
PCIE_RXN0
42
N/C
43
PCIE_RXP0
44
N/C
45
GND
46
N/C
47
PCIE_TXN0
48
N/C
49
PCIE_TXP0
50
PERST#
51
GND
52
CLKREQ#
53
REFCLKN
54
PEWAKE
55
REFCLKP
56
N/C
57
GND
58
N/C
59
N/C
60
N/C
61
N/C
62
N/C
63
N/C
64
N/C
65
N/C
66
N/C
67
WWAN_RST
68
N/C
69
PEDET
70
+3.3V
71
GND
72
+3.3V
73
GND
74
+3.3V
75
CONFIG_2
Table 3-23: M. 2 B key Slot Pinouts
