IEI Technology WEB-6580 User Manual

BIOS Setup Information
WEB-6580 【 R1.0 】 User’s Manual 4-20
If user wants to install different add-on super I/O card to connect floppy
drives, set this field to Disabled. Otherwise, set it to Auto to call BIOS to
automatically determine if the floppy controller should be enabled.
On Board Serial Port 1/Port 2
These fields control the resource assignments of two on-board serial
interfaces SIO1 and SIO2. The following lists show current options in On
Board Serial Port 1/ Port 2 :
Auto  cannot set serial I/O resources by manual operation
Disabled  indicates on-board COM port function is ineffective
3F8h/COM1  assign I/O address 3F8h to COM1
2F8h/COM2  assign I/O address 2F8h to COM2
3E8h/COM3  assign I/O address 3E8h to COM3
2E8h/COM4  assign I/O address 2E8h to COM4
Serial Port2 Mode
This option control the resource assignments of on-board Serial Port2. The
Serial Port2 Mode Select has Four settings Normal, IrDA, and ASK IR.
Duplex Mode
Duplex Mode has two settings Half Duplex and Full Duplex
On Board Parallel Port
