ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
TCP/IP object (object class: 0xF5)
23127
TCP/IP Interface Object enables the configuration of the physical network interface of the device.
>
Class attributes
23647
Attr ID
Access
Name
Data type
Description
Value
1
Get
Revision
UINT
Revision of the object
4
2
Get
Max instance
UINT
Max. number of instances of the object
1
>
Instance attributes
23650
Attr.
ID
Access
Name
Data type
Description
Preset
1
Get
Status
DWORD
Status of the TCP/IP interface
Bit
0...3
Configuration status of the interface
Bit 4
Mcast pending (always 0)
Bit 5
Interface configuration pending
Bit 6
ACD Status
Bit 7
ACD Fault
Bit
8...31
reserved
2
Get
Configuration Capability
DWORD
Functions of the interface (flags)
0x95
(BOOTP,DHCP
Client,TCP/IP
configurable,
ACD capable)
Bit 0
BOOTP Client
Bit 1
reserved
Bit 2
DHCP Client
Bit 3
reserved
Bit 4
TCP/IP configurable via EtherNet/IP
Bit 5
reserved
Bit 6
reserved
Bit 7
ACD Capable
Bit
8...31
reserved
3
Get/Set
Configuration Control
DWORD
Interface control (control flags):
0
Bit
0...3
Start-up configuration
0
Static IP configuration
1
Configuration via BOOTP
2
Configuration via DHCP
Bit 4
reserved
Bit
5...31
reserved
4
Get
Physical Link Object path
STRUCT:
Logical path to the physical communication
interface: the Ethernet Link object
