ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
12.1.1 Application
23710
Application
Application
I/O modules for field applications
Daisy-chain function
Communication interface
>
12.1.2 Electrical data
22819
Electrical data
Operating voltage
20...30 DC; (US; to SELV/PELV)
Current Consumption [mA]
300...3900; (US)
Protection class
III
Sensor supply US
Max. current load total [A]
3.6
>
12.1.3 Inputs / outputs
23711
Inputs / outputs
Total number of inputs and outputs
16; (configurable)
>
12.1.4 Inputs
22820
Inputs
Number of digital inputs
16; (IO-Link Port Class A: 8 x 2)
Switching level high [V]
11...30 DC
Switching level low [V]
0...5 DC
Digital inputs protected against short circuits
yes
>
12.1.5 Outputs
22821
Outputs (digital)
Output function
8; (IO-Link Port Class A: 8 x 1)
Max. current load per output [mA]
200
Short-circuit protection
yes
>
