ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
Device Level Ring Object (object class: 0x47)
23657
The Device Level Ring (DLR) Object represents the interface for configuration and status information.
>
Class attributes
23658
Attr ID
Access
Name
Data type
Description
Value
1
Get
Revision
UINT
Revision of the object
3
2
Get
Max instance
UINT
Max. number of instances of the object
1
6
Get
Maximum ID Number
Class Attributes
UINT
ID of the last class attribute
7
7
Get
Maximum ID Number
Instance Attributes
UINT
ID of the last instance attribute
12
>
Instance attributes
23659
Attr. ID
Access
Name
Data type
Description
Preset
1
Get
Network
Topology
USINT
current network topology
0
2
Get
Network status
USINT
current network status
0
10
Get
Active Supervisor
STRUCT of
Identification of the supervisor
0
 UDINT
IP address of the supervisor
 ARRAY
of 6
USINT
s
MAC address of the supervisor
12
Get
Capability Flags
DWORD
DLR functions of the device
0x82
Bit 0
Announced-based ring node
0
Bit 1
Beacon-based ring node
1
Bit 2...4
reserved
--
Bit 5
Supervisor capable
0
Bit 6
Redundant Gateway capable
0
Bit 7
Flush_Table frame capable
1
Bit 8..31
reserved
--
l
>
Supported services
23660
Service code
Name
Class
Attribute
Description
dec
hex
1
01
Get_Attribute_All
no
yes
Read all attribute values
14
0E
Get_Attribute_Single
yes
yes
Read single attribute value
