ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Configuration
>
8.6.2 Write cyclic output data
8570
The user can access the cyclic output data of the connected actuators and IO-Link devices via the
controller tags of the AL1122.
To access the cyclic output data:
► Starting RSLogix5000.
► Open a EtherNet/IP project.
► In the project tree: Mouse click on [Controller Tags] > [AL1122.O]
> The window shows the data structure with cyclic input data ([AL1122.O:Data])
Mapping of the outputs on the data structure [AL1122.C:O]: → Output assembly (→ p. 76)).
