ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Operation
>
9.4 Firmware update
22425
The new firmware is installed via the device's web interface.
If the firmware update is not successful, deactivate all connections to the EtherNet/IP PLC, LR
SmartObserver and LR DEVICE and repeat the process.
► Stop EtherNet/IP PLC.
► Set the parameter [IP address SmartObserver] to 255.255.255.255 (→ Configure the
interface to the SmartObserver (→ p. 35)).
► Stop the LRAgent.LRDevice service in the Windows task manager.
To install a new firmware version on the device:
Requirements
> File with new firmware has been downloaded.
> Ethernet connection between laptop/PC and device is established.
1 Call up web interface
► Start web browser.
► Enter the following into the address field of the browser: and confirm with [ENTER]:
<IP-Adresse des Geräts>/update
> Web browser shows the [Firmware Update] page.
2 Load new firmware to AL1122
► Click on [Datei auswählen].
> Dialogue window appears.
► Select the firmware file and click on [Öffnen] in order to adopt the file.
► Click on [Submit] to start the firmware update.
> Firmware is being loaded to the device.
> After successful storage, the success message is displayed
3 Restart the device
► Click on [Restart device now] to restart the device.
> The status LED RDY flashes quickly.
> Firmware is updating.
► Follow the instructions in the browser.
