ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Function
>
4.1.1 IO-Link
7773
The device offers the following IO-Link functions:
IO-Link master for connection of up to 8 IO-Link devices (sensors, actuators) according to IO-Link
standard 1.0 and 1.1.
Provision of process data of the connected IO-Link devices for LR SmartObserver monitoring
software (→ www.ifm-datalink.com)
>
4.1.2 EtherNet/IP
2259
The device offers the following EtherNet/IP functions:
Provision of the functions of a EtherNet/IP Device
2 port switch for access to the EtherNet/IP interface (X21/X22)
Gateway for transmission of the process and parameter data between the connected IO-Link
devices and the higher-level EtherNet/IP controller
>
4.1.3 Parameter setting
7771
The device provides the following configuration options:
Parameter setting of the IO-Link master of the AL1122 with parameter setting software LR
DEVICE and/or EtherNet/IP projection software
Parameter setting of the connected IO-Link devices (sensors, actuators) with parameter setting
software LR DEVICE and/or EtherNet/IP projection software
Storage of parameter sets of the connected IO-Link devices for automatic recovery (data storage)
>
4.1.4 Visual indication
7772
The device has the following visual indicators:
Status and error indication of the gateway, of the EtherNet/IP connection and of the system
Status display of the voltage supply
Status and activity display of the Ethernet connection
Status, error and short circuit/overload indication of the IO-Link ports
