ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Operating and display elements
>
7.2 LED indicators
22024
The device only has the following LED indicators:
>
7.2.1 Status LEDs
7707
The RDY LED indicates the status of the gateway.
The NET LED (Network Status) indicates the status of the network.
The MOD LED (Module Status) indicates the status of the EtherNet/IP module.
Status LED
Description
RDY
green
on
Gateway functions properly
flashes 1 Hz
Error
flashes 5 Hz
Firmware update
off
Gateway does not function; Device reboots
NET
green
on
Connection with the EtherNet/IP PLC
off
No IP address
red
on
IP address is used twice
flashes
No connection with the EtherNet/IP PLC
MOD
green
on
No error
off
Voltage too low
red
on
Module failed
flashes
Configuration of the module has been changed
>
7.2.2 Ethernet interface
22027
Each Ethernet interface (X21, X22) has 2 LEDs (LNK and ACT). The LEDs indicate the status of the
Ethernet connection.
Status LED
Description
LNK
green
on
Ethernet connection established
off
No Ethernet connection
ACT
yellow
flashes
Data is transmitted via the Ethernet interface.
off
No data transmission
