8.2.4 Set the operating mode of the IO-Link ports
8714
The IO-Link ports X01...X08 of the device support the following operating types:
 Digital input (DI): binary input signal on pin 4 (C/Q) of the IO-Link port
 Digital output (DO): binary output signal on pin 4 (C/Q) of the IO-Link port
 IO-Link interface (IO-Link): IO-Link data transfer via pin 4 (C/Q) of the IO-Link port
The user can set the operating mode of each IO-Link port separately at any time.
► Select [Port x] menu.
> The page shows the current settings.
► Set the following parameters as required:
Name
Description
Possible values
[Port x mode]
Operating mode of the IO-Link
port (x = 1...8)
IO-Link
Operation as IO-Link interface
DI
Operation as digital input
DO
Operation as digital output
Disabled
Interface deactivated
[Port x IO-Link. Cycle time]*
Cycle time of the data
transmission between the IO-Link
master and the IO-Link device
As fast as possible
The device automatically sets the
fastest possible cycle time
2.0 ms
...
128.0 ms
2 milliseconds
...
128 milliseconds
* ... Parameter only available, if [Port x mode] = IO-Link
> Store the changed values on the AL1122.
