ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
Connection Manager Object (object class: 0x06)
23698
The Connection Manager Object structures and manages the internal resources that are used for the
connection.
>
Class attributes
23699
Attr ID
Access
Name
Data type
Description
Value
1
Get
Revision
UINT
Revision of the object
1
2
Get
Max instance
UINT
Max. number of instances of the object
1
3
Get
Number of Instances
UINT
Number of instances
3
6
Get
Maximum ID Number
Class Attributes
UINT
ID of the last class attribute
7
7
Get
Maximum ID Number
Instance Attributes
UINT
ID of the last instance attribute
0
>
Instance attributes
23696
The object has no instance attributes.
>
Supported services
23701
Service code
Name
Class
Attribute
Description
dec
hex
14
0E
Get_Attribute_Single
yes
yes
Read single attribute
16
10
Set_Attribute_Single
no
yes
Change single attribute
78
4E
Forward_Close
yes
no
Close connection
84
54
Forward_Open
yes
no
Open new connection
