ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Operation
>
9.2 Reboot the device
12760
When restarting the device, all settings are kept.
To restart the AL1122:
► Start LR DEVICE.
► Scan the network for devices.
> LR DEVICE recognises the AL1122.
► Under [ONLINE]: Click on [AL1122]
► Select the [Setup] section.
> LR DEVICE shows available parameters.
► Click on [Restart] to restart the device.
> LR DEVICE restarts the AL1122.
>
9.3 Error detection and elimination
20926
In order to recognise and eliminate errors, the user can use the following resource:
 Status LED of the unit (→ LED indicators (→ p. 24))
 Cyclic diagnostic and status information (→ Input assembly (→ p. 72))
