Assembly Object (object class: 0x04)
23690
The Assembly Object combines attributes of several objects to allow data to be sent to or received
from each object via one connection.
>
Class attributes
23691
Attr. ID
Access
Name
Data type
Description
Value
1
Get
Revision
UINT
Revision of the object
2
2
Get
Max instance
UINT
Max. number of instances of the object
0x00C7
3
Get
Number of Instances
UINT
Number of instances
3
6
Get
Maximum ID Number
Class Attributes
UINT
ID of the last class attribute
7
7
Get
Maximum ID Number
Instance Attributes
UINT
ID of the last instance attribute
4
>
Instance attributes
23692
Attr. ID
Access
Name
Data type
Description
Preset
100
Get
Input assembly
STRUCT
Cyclic input data (→ Input assembly (→ p. 72))
--
150
Get, Set
Output assembly
STRUCT
Cyclic output data (→ Output assembly (→ p. 76))
--
199
Get, Set
Configuration
assembly
STRUCT
Configuration data (→ Configuration assembly
(→ p. 68))
--
>
Supported services
23693
Service code
Name
Class
Attribute
Description
dec
hex
14
0E
Get_Attribute_Single
yes
yes
Read attribute value
16
10
Set_Attribute_Single
no
yes
Change attribute value
