ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
Configuration assembly
10234
The values of the Configuration Assembly are set in RSLogix 5000 via the controller tags of
the EtherNet/IP project.
Bytes
Contents
0
Communication profile (→ Communication profile (→ p. 69))
1
Process Data Length (→ Process data length (→ p. 69))
2
X01: Operating mode (→ Port configuration (→ p. 70))
3
X01: Cycle time IO-Link master - IO-Link device (→ Port configuration (→ p. 70))
4
X01: Byte swap (→ Port configuration (→ p. 70))
5
X01: Data storage and validation (→ Port configuration (→ p. 70))
6
X01: Vendor ID (LSB) (→ Port configuration (→ p. 70))
7
X01: Vendor ID (MSB) (→ Port configuration (→ p. 70))
8
X01: Device ID (LSB) (→ Port configuration (→ p. 70))
9
X01: Device ID (→ Port configuration (→ p. 70))
10
X01: Device ID (MSB) (→ Port configuration (→ p. 70))
11
X01: reserved
12
X01: Fail Safe Mode (→ Port configuration (→ p. 70))
13
X01: Fail safe value of DO (pin 4) (→ Port configuration (→ p. 70))
14...25
X02: Port configuration (→ row 2...13)
26...37
X03: Port configuration (→ row 2...13)
38...49
X04: Port configuration (→ row 2...13)
50...61
X05: Port configuration (→ row 2...13)
62...73
X06: Port configuration (→ row 2...13)
74...85
X07: Port configuration (→ row 2...13)
86...97
X08: Port configuration (→ row 2...13)
