ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
Port configuration
7423
Name
Description
Possible values
[X0n: Port Mode]
Operating mode of the IO-Link port
0x00
Interface deactivated
0x01
Operation as digital input (DI)
0x02
Operation as digital output (DO)
0x03
Operation as IO-Link interface
[X0n: Master Cycle
Time]
Cycle time of the data transmission between
the IO-Link master and the IO-Link device
0x00
The device automatically sets the fastest
possible cycle time
0x01
2 milliseconds
0x02
4 milliseconds
0x03
8 milliseconds
0x04
16 milliseconds
0x05
32 milliseconds
0x06
64 milliseconds
0x07
128 milliseconds
[X0n: Byte Swap]
Visualisation of the process data (EtherNet/IP
uses Little Endian Format (Intel), IO-Link uses
Big Endian Format (Motorola))
0x00
Byte swapping for IO-Link process data
deactivated
0x01
Byte swapping for IO-Link process data
activated
[X0n: Validation ID]
Supported IO-Link standard and behaviour of
the IO-Link master when connecting new
IO-Link devices to the IO-Link port
0x00
No validation
0x01
Type compatible V1.0 device
0x02
Type compatible V1.1 device
0x03
Type compatible V1.1 device with Backup +
Restore
0x04
Type compatibe V1.1 device with Backup
[X0n: VID (LSB)]
Vendor ID of the manufacturer of the device
on the IO-Link port
per byte: 0x00...0xFF
0xYYZZ
- YY = VID (MSB)
- ZZ = VID (LSB)
[X0n: VID (MSB)]
[X0n: DID (LSB)]
Device ID of the device on the IO-Link port
per byte: 0x00...0xFF
0xXXYYZZ
- XX = DID (MSB)
- YY = DID
- ZZ = DID (LSB)
[X0n: DID]
[X0n: DID (MSB)]
[X0n: Fail-safe
Mode]
Fail-safe mode for output data when the
EtherNet/IP connection is interrupted
0x00
No Failsafe
0x01
Failsafe Reset Value
0x02
Failsafe Old Value
0x03
Failsafe with Pattern
[X0n: Fail-safe
Value of DO Pin 4]
Fail-safe value for the operating mode "digital
output (DO)"
0x00
Failsafe Reset Value
0x01
Failsafe Old Value
0x02
Failsafe Set Value
