ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
Message Router Object (object class: 0x02)
23694
The Message Router Object provides an access with which an EtherNet/IP client can address a
service to any object class or instance in the physical device.
>
Class attributes
23695
Attr. ID
Access
Name
Data type
Description
Value
1
Get
Revision
UINT
Revision of the object
1
2
Get
Max instance
UINT
Max. number of instances of the object
1
3
Get
Number of Instances
UINT
Number of instances
1
6
Get
Maximum ID Number
Class Attributes
UINT
ID of the last class attribute
7
7
Get
Maximum ID Number
Instance Attributes
UINT
ID of the last instance attribute
0
>
Instance attributes
23696
The object has no instance attributes.
>
Supported services
23697
Service code
Name
Class
Attribute
Description
dec
hex
14
0E
Get_Attribute_Single
yes
no
Read single attribute value
