ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
CIP class services
23651
The device supports the following class and instance services:
Class code
Service
Description
dec
hex
01
01
Get Attribute All
Read all attribute values of the class or instance
02
02
Set Attribute All
Change all attribute values of the class or instance
05
05
Reset
Reset
09
09
Delete
Delete
14
0E
Get Attribute Single
Read single attribute value of the class or instance
16
10
Set Attribute Single
Change single attribute value of the class or instance
75
4B
Read ISDU
Read ISDU
76
4C
Write ISDU
Write ISDU
78
4E
Forward Close
Close connection
84
54
Forward Open
Open new connection
>
CIP object classes
23652
The device supports the following CIP object classes:
Class code
Object type
Reference
dec
hex
01
01
Identity Object
→ Identity Object (object class: 0x01) (→ p. 90)
02
02
Message Router Object
→ Message Router Object (object class: 0x02) (→ p. 92)
04
04
Assembly Object
→ Assembly Object (object class: 0x04) (→ p. 93)
06
06
Connection Manager Object
→ Connection Manager Object (object class: 0x06) (→ p. 94)
71
47
Device Level Ring Object
→ Device Level Ring Object (object class: 0x47) (→ p. 95)
72
48
Quality of Service
→ Quality of Service (object class: 0x48) (→ p. 96)
128
80
IO-Link Requests
→ IO-Link requests (object class: 0x80) (→ p. 97)
245
F5
TCP/IP Object
→ TCP/IP object (object class: 0xF5) (→ p. 104)
246
F6
Ethernet Link Object
→ Ethernet Link Object (object class: 0xF6) (→ p. 106)
