ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Function
>
4.2 Digital inputs
7584
The device has 8 digital inputs (type 2 according to EN 61131-2).
The digital inputs are on pin 2 of the IO-Link ports X01 ... X08.
All inputs refer to the potential of the device supply (pin 3).
>
4.3 IO-Link supply
7623
The device has 8 supplies for IO-Link devices (sensors, actuators).
The IO-Link ports X01...X08 are ports class A.
Every supply provides short circuit monitoring.
The device ensures fire protection for the connected IO-Link devices by providing a power-restricted
circuit at the IO-Link ports (according to IEC61010-1).
