9.1.2 LR DEVICE: Read device information
11614
To show information about the AL1122:
► Start LR DEVICE.
► Scan network for devices.
> LR DEVICE shows recognised AL1122.
► Mouse click on AL1122
> The header shows the following information:
Name
Description
Possible values
Device name
Article number of the device
AL1122
Manufacturer
Manufacturer of the device
ifm electronic gmbh
Device ID
IO-Link ID of the device
Serial number
Serial number of the device
Revision
Hardware revision / software revision of
the unit
Type of unit
Name of the device
IO-Link master StandardLine EtherNet/IP 8 ports IP 65 /
IP 67
Device status
Current status of the slave
no information about the condition
OK: no errors, no warning, no information
OK: no errors, no warning, information
Warning
Error
>
9.1.3 EtherNet/IP: Read device information
7639
The user can read information about the device via the field bus object "Identity Object" (→ Field bus
objects (→ p. 88)).
