Appendix
>
Output assembly
9214
Byte
Content
0
Digital output data of the IO-Link ports in the DO operating mode (→ Mapping: Digital output data (DO) (→ p. 76))
1
reserved
2
reserved
3
reserved
4...45
Acyclic command area: Request channel (→ Request channel (→ p. 78))
46
Port X01: Acyclic output data (n bytes)
46+n
Port X02: Acyclic output data (n bytes)
46+2n
Port X03: Acyclic output data (n bytes)
46+3n
Port X04: Acyclic output data (n bytes)
46+4n
Port X05: Acyclic output data (n bytes)
46+5n
Port X06: Acyclic output data (n bytes)
46+6n
Port X07: Acyclic output data (n bytes)
46+7n
Port X08: Acyclic output data (n bytes)
Legend:
n = [2,4,8,16,32]; is determined by the parameter [Prozess_Data_Length] (→ Process data length (→ p. 69))
>
Mapping: Digital output data (DO)
19841
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X08: Pin 4
X07: Pin 4
X06: Pin4
X05: Pin 4
X04: Pin 4
X03: Pin 4
X02: Pin 4
X01: Pin 4
Legend:
X0n: Pin 4
Signal level on pin 4 of the
IO-Link port
1 bit
0x0 = OFF
0x1 = ON
