ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Configuration
Name
Description
Possible values
[AL1122:C.Device_ID_Port_x]
Device ID of the device on the
IO-Link port
0x000000...0xFFFFFF
[AL1122:C.Fail_Safe_Mode_Port_x]
Fail-safe mode for output data
when the EtherNet/IP
connection is interrupted
0x00
No Failsafe
0x01
Failsafe Reset Value
0x02
Failsafe Old Value
0x03
Failsafe with Pattern
[AL1122:C.Fail_Safe_Value_DO_Port_x]
Fail-safe value for the
operating mode "digital output
(DO)"
0x00
Failsafe Reset Value
0x01
Failsafe Old Value
0x02
Failsafe Set Value
x = 1...8
► <Save EtherNet/IP project.
