ifm Operating Instructions IO-Link Master with EtherNet/IP interface StandardLine 8 Ports IP 65 / IP 67 (AL1122) 2017-05-31
Appendix
>
Command response
8039
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
4
Port no. (LSB)
5
Port no. (MSB)
6
reserved
7
reserved
8
reserved
9
reserved
10
Handshake
0x10
11
Result
12
Target Mode
13...45
reserved
Legend:
Port no. (LSB)
Number of the IO-Link port
(low byte)
Port no. = 0xXXYY
 Port no. (LSB) = 0xYY
8 bits
0x01 = port X01
0x02 = port X02
...
0x08 = Port X08
Port no. (MSB)
Number of the IO-Link port
(high byte)
Port no. = 0xXXYY
 Port no. (MSB) = 0xXX
8 bits
0x00
Handshake
Status of the execution of the
command
1 bit
0x0 = command is executed
0x1 = execution of the command was successful
Result
Error indication
8 bits
0x00 = no errors
0x01 = errors occurred
Target mode
Operating type of the IO-Link
port
8 bits
0x00 = deactivated
0x01 = operation as digital input (DI)
0x02 = operation as digital output (DO)
0x03 = operation as IO-Link intervals
