10.2 Explanation of the menu
10.2.1 Main menu
tREF Carry out a tank adjustment�
Menu item only visible if [LEnG] ≥ 260 mm.
SP1 /
rP1
Set point 1 / reset point 1 at which OUT1 switches�
Menu item only visible if hysteresis function is selected ([ou1] = [H��])�
FH1 /
FL1
Upper / lower limit for the acceptable range within which OUT1 switches� Menu
item only visible if window function is selected ([ou1] = [F��])�
ASP2
Analogue start point 2: measured value at which the analogue start value is
provided� The analogue start point is set with parameter [ou2]�
Menu item only visible if analogue output ([ou2] = [I] or [InEG]) is selected�
AEP2
Analogue end point 2: measured value at which the analogue end value is
provided� The analogue end value is set with parameter [ou2]�
Menu item only visible if analogue output ([ou2] = [I] or [InEG]) is selected�
SP2 /
rP2
Set point 2 / reset point 2 at which OUT2 switches�
Menu item only visible if hysteresis function is selected ([ou2] = [H��])�
FH2 /
FL2
Upper / lower limit for the acceptable range within which OUT2 switches�
Menu item only visible if window function is selected ([ou2] = [F��])�
EF
Extended functions / opening of menu level 2
10.2.2 Level EF (extended functions)
rES Restore the factory setting (all parameters incl� tank adjustment)
CFG Open the submenu CFG (configuration)
ENV Open the submenu ENV (environment parameter)
SIM
Open the submenu SIM (simulation)
