SETUP
DMS3-CTC-25-115 v1.0
15
2
2.3 Connecting your wired devices
Requirements
Both your network device (for example, a computer, a gaming console,...) and TG-1 Gateway must have
a free Ethernet port.
Your network device must be configured to obtain an IP address automatically. This is the default setting.
Ethernet cable
In your package, you will find a cable with yellow connectors. This is the Ethernet cable.
Procedure
Proceed as follows:
1 Connect one end of the Ethernet cable to one of the yellow Ethernet ports of your TG-1 Gateway:
2 Connect the other end of the Ethernet cable to your network device.
3 Your device is now connected to your network.
To connect a wireless devices, see “3 Wireless networking” on page 18.
The TG-1 Gateway does not support Power over Ethernet (PoE). All network devices that are
connected to the TG-1 Gateway must be powered by their own power source.
Ethernet cable
Ethernet device
(e.g. a computer)
