2.2 Powering on the TG-1 Gateway
Procedure
Proceed as follows:
1 Plug the connector of the electric Power Supply Unit (PSU) into the TG-1 Gateway power inlet port
( ). Plug the PSU into a nearby power outlet.
2 Press the power button ( ) to turn on the TG-1 Gateway.
3 The Status ( ) LED lights up. Wait two minutes to allow the TG-1 Gateway to complete the start up
phase.
Power outlet
PSU
