3.1 HDTV Format
The following section indicates the lists of HDTV formats, output formats, and signal formats indicated on the BS/CCU menu and
the self-diagnosis display screen (Diagnostic Information).
Menu screen notation Format SDI signal Standard
1080I59 1920 x 1080 interlace 60/M 1080i59.94 1.485/M Gbps 422 274M/292M
1080P23PD 1920 x 1080 2-3 pulldown 24/M 1080i59.94 1.485/M Gbps 422 274M/292M
1080P23SF 1920 x 1080 progressive(sF) 24/M 1080psF23.98 1.485/M Gbps 422 274M/292M
1080P23 1920 x 1080 progressive 24/M 1080p23.98 1.485/M Gbps 422 274M/292M
1080P29SF 1920 x 1080 progressive(sF) 30/M 1080psF29.97 1.485/M Gbps 422 PR211/292M
1080P29 1920 x 1080 progressive 30/M 1080p29.97 1.485/M Gbps 422 274M/292M
720P59 1280 x 720 progressive 60/M 720p59.94 1.485/M Gbps 422 296M/292M
1080I50 1920 x 1080 interlace 50 1080i50 1.485 Gbps 422 274M/292M
1080P25SF 1920 x 1080 progressive(sF) 25 1080psF25 1.485 Gbps 422 PR211/292M
1080P25 1920 x 1080 progressive 25 1080p25 1.485 Gbps 422 274M/292M
720P50 1280 x 720 progressive 50 720p50 1.485 Gbps 422 296M/292M
1080P59 3G-SDI 1920 x 1080 progressive 60/M 1080p59.94 2.970/M Gbps 422 274M/425M
1080P59 DUAL-LINK 1920 x 1080 progressive 60/M 1080p59.94 2x 1.485/M Gbps 422 274M/372M
1080I59 3G-SDI 1920 x 1080 interlace 60/M 1080i59.94 2.970/M Gbps 444 274M/425M
1080I59 DUAL-LINK 1920 x 1080 interlace 60/ M 1080i59.94 2x 1.485/M Gbps 444 274M/372M
1080P23PD 3G-SDI 1920 x 1080 2-3 pulldown 24/M 1080i59.94 2.970/M Gbps 444 274M/425M
1080P23PD DUAL-LINK 1920 x 1080 2-3 pulldown 24/M 1080i59.94 2x 1.485/M Gbps 444 274M/372M
1080P23SF 3G-SDI 1920 x 1080 progressive(sF) 24/M 1080psF23.98 2.970/M Gbps 444 PR211/425M
1080P23SF DUAL-LINK 1920 x 1080 progressive(sF) 24/M 1080psF23.98 2x 1.485/M Gbps 444 PR211/372M
1080P23 3G-SDI 1920 x 1080 progressive 24/M 1080p23.98 2.970/M Gbps 444 274M/425M
1080P23 DUAL-LINK 1920 x 1080 progressive 24/M 1080p23.98 2x 1.485/M Gbps 444 274M/372M
1080P29SF 3G-SDI 1920 x 1080 progressive(sF) 30/M 1080psF29.97 2.970/M Gbps 444 PR211/425M
1080P29SF DUAL-LINK 1920 x 1080 progressive(sF) 30/M 1080psF29.97 2x 1.485/M Gbps 444 PR211/372M
1080P29 3G-SDI 1920 x 1080 progressive 30/M 1080p29.97 2.970/M Gbps 444 274M/425M
1080P29 DUAL-LINK 1920 x 1080 progressive 30/M 1080p29.97 2x 1.485/M Gbps 444 274M/372M
1080I119 3G-SDI 1920 x 1080 interlace 120/M 1080i119.88 2.970/M Gbps 422 EVS
1080I119 DUAL-LINK 1920 x 1080 interlace 120/M 1080i119.88 2x 1.485/M Gbps 422 EVS
1080P50 3G-SDI 1920 x 1080 progressive 50 1080p50 2.970 Gbps 422 274M/425M
1080P50 DUAL-LINK 1920 x 1080 progressive 50 1080p50 2x 1.485 Gbps 422 274M/372M
1080I50 3G-SDI 1920 x 1080 interlace 50 1080i50 2.970 Gbps 444 274M/425M
1080I50 DUAL-LINK 1920 x 1080 interlace 50 1080i50 2x 1.485 Gbps 444 274M/372M
1080P25SF 3G-SDI 1920 x 1080 progressive(sF) 25 1080psF25 2.970 Gbps 444 PR211/425M
1080P25SF DUAL-LINK 1920 x 1080 progressive(sF) 25 1080psF25 2x 1.485 Gbps 444 PR211/372M
1080P25 3G-SDI 1920 x 1080 progressive 25 1080p25 2.970 Gbps 444 274M/425M
1080P25 DUAL-LINK 1920 x 1080 progressive 25 1080p25 2x 1.485 Gbps 444 274M/372M
1080I100 3G-SDI 1920 x 1080 interlace 100 1080i100 2.970 Gbps 422 EVS
1080I100 DUAL-LINK 1920 x 1080 interlace 100 1080i119.88 2x 1.485 Gbps 422 EVS
sF : segmented Frame
/M : I represent the /1.001
EVS : Outputs that correspond to the video servers of EVS Broadcast Equipment (TM).
In order to use above output formats, it is prerequisite that the camera head to be connected is a compatible type.
When the camera head that is not compatible is connected, the connected camera head cannot be selected.
To Next Page
