79
BS-98 1409 VER1 (U) (E)
5.1 Settings from the BS Menu
HDTV VIDEO PROCESS
HDTV VIDEO PROCESS sets the various HDTV video processes.
▲
ＨＤＴＶ ＶＩＤＥＯ ＰＲＯＣＥＳＳ
ＳＤＴＶ ＶＩＤＥＯ ＰＲＯＣＥＳＳ
ＨＤ ＰＭ ＶＩＤＥＯ ＰＲＯＣＥＳＳ
ＳＤ ＰＭ ＶＩＤＥＯ ＰＲＯＣＥＳＳ
ＦＵＮＣＴＩＯＮ ＳＥＴＴＩＮＧ
ＥＮＧＩＮＥＥＲ ＳＥＴ ＦＩＬＥ ＲＥＮＥＷ
ＰＲＯＧＲＡＭ ＵＰＤＡＴＥ
▼
＊＊＊ ＥＮＧＩＮＥＥＲ（２／２） ＊＊＊
ＧＡＭＵＴ ＣＬＩＰ −−−
ＬＥＶＥＬ −−−
ＨＤＴＶ ＢＡＲＳ ＴＹＰＥ ＳＭＰＴＥ
ＡＲＩＢ ＢＡＲＳ ＴＹＰＥ −−−
ＳＭＰＴＥ ＢＡＲＳ ＴＹＰＥ１ ７５％
ＳＭＰＴＥ ＢＡＲＳ ＴＹＰＥ２ ０％
ＣＨＡＲ ＬＥＶＥＬ −−−
ＣＨＡＲ ＢＧ ＬＥＶＥＬ −−−
ＨＤＴＶ ＶＩＤＥＯ ＰＲＯＣＥＳＳ
To position the flashing cursor on
the "HDTV VIDEO PROCESS", and
determine.
The submenu "HDTV VIDEO PROCESS"
is displayed, on which you can perform
various settings.
Setting Item Set Value Description
GAMUT CLIP
LEVEL
ON Sets ON / OFF of GAMUT CLIP.
98.0% to 109.0% Sets CLIP LEVEL of GAMUT CLIP ON time.
HDTV BARS TYPE SMPTE Sets the HDTV color bar complying with the SMPTE-standard color bar.
ARIB Sets the HDTV color bar complying with the ARIB-standard multi-format color bar.
100/75 Sets the HDTV color bar complying with the 100/0/75/0 color bar.
100/100 Sets the HDTV color bar complying with the 100/0/100/0 color bar.
75/75 Sets the HDTV color bar complying with the 75/0/75/0 color bar.
ARIB BARS TYPE 75% Sets the pattern 2 of the ARIB-standard color bar to "75% White".
100% Sets the pattern 2 of the ARIB-standard color bar to "100% White".
+I Sets the pattern 2 of the ARIB-standard color bar to "+I signal".
SMPTE BARS TYPE1 75% Sets the pattern 2 of the SMPTE-standard color bar to "75% White".
100% Sets the pattern 2 of the SMPTE-standard color bar to "100% White".
+I Sets the pattern 2 of the SMPTE-standard color bar to "+I signal".
-I Sets the pattern 2 of the SMPTE-standard color bar to "-I signal".
SMPTE BARS TYPE2 0% Sets the pattern 3 of the SMPTE-standard color bar to "0% Black".
+Q Sets the pattern 3 of the SMPTE-standard color bar to "+Q signal".
CHAR LEVEL ----- Sets the character level of the HDTV OUT signals. Sets in the factory.
CHAR BG LEVEL ----- Sets the background level of characters on the HDTV OUT signals. Factory setting.
