Ikegami BS-98 - Output Format

71
BS-98 1409 VER1 (U) (E)
5.1 Settings from the BS Menu
OUTPUT FORMAT
Set the output format of each output.
▲
ＳＹＳＴＥＭ ＦＯＲＭＡＴ
ＯＵＴＰＵＴ ＦＯＲＭＡＴ
ＲＥＴ ＶＩＤＥＯ ＦＯＲＭＡＴ
ＰＨＡＳＥ ＣＯＮＴＲＯＬ
ＭＩＣ ＭＡＮＡＧＥＭＥＮＴ
ＩＮＣＯＭ ＭＡＮＡＧＥＭＥＮＴ
▼
＊＊＊ ＥＮＧＩＮＥＥＲ（１／２） ＊＊＊
ＯＵＴ−１ １０８０Ｐ５９ ＹＣ ３Ｇ
ＯＵＴ−２ １０８０Ｐ５９ ＹＣ ３Ｇ
ＯＵＴ−３ １０８０Ｉ５９ ＹＣ ＨＤ
ＰＭ−１ ＰＭ ＨＤ−ＳＤＩ
ＰＭ−２／ＷＦＭ ＷＦＭ （ＯＵＴ−３）
ＨＤ ＰＭ １０８０Ｉ５９ ＹＣ ＨＤ
ＳＤ ＳＣＲＥＥＮ ＭＯＤＥ ４：３
ＳＹＮＣ ＯＵＴ １０８０Ｉ５９
ＨＤ−ＳＹＮＣ ２−３ＩＤ ＡＤＤ −−−
ＳＤ−１０ＦＩＥＬＤ ＩＤ ＳＩＧ −−−
ＯＵＴＰＵＴ ＦＯＲＭＡＴ
１０８０Ｐ５９ ＹＣ ４２２ ３Ｇ−ＳＤＩ ◎
１０８０Ｐ５９ ＹＣ ４２２ ＤＵＡＬ−ＬＩＮＫ ○
１０８０Ｉ５９ ＹＣ ４２２ ＨＤ−ＳＤＩ ○
ＯＵＴ−１
Set the blinking cursor to "OUTPUT
FORMAT" and finalize.
The sub menu "OUTPUT FORMAT" is
displayed.
When "OUT-1", "OUT-2", "OUT-3", and
"HD PM" are selected, sub menus open,
and the format select screen opens.
The figure is OUT-1 select screen when
the SYSTEM FORMAT is 1080P59 3G
as one example.
Items that can be selected vary
depending on each format and output
system.
１０８０Ｐ２３ＰＤ ＹＣ ４２２ ＨＤ−ＳＤＩ ○
１０８０Ｐ２３ＳＦ ＹＣ ４２２ ＨＤ−ＳＤＩ ◎
１０８０Ｐ２３ ＹＣ ４２２ ＨＤ−ＳＤ ○
ＯＵＴ−１
OUT-1 selects 1080P23SF.
Note:
For converter output
When 1080P23PD is selected in SYSTEM
FORMAT, the select-able FORMAT
of each output are three types that are
1080P23PD, 1080P23SF, and 1080P23.
Within these, 1080P23SF and 1080P23
use the converter; therefore, only one of
these can be selected.
Simultaneous output of 1080P23SF and
1080P23 is not possible.
1080P23PD and 1080P23SF or
1080P23PD and 1080P23 are the
simultaneous output.
１０８０Ｐ２３ＰＤ ＹＣ ４２２ ＨＤ−ＳＤＩ ◎
１０８０Ｐ２３ＳＦ ＹＣ ４２２ ＨＤ−ＳＤＩ ○
１０８０Ｐ２３ ＹＣ ４２２ ＨＤ−ＳＤＩ ×
ＯＵＴ−２
OUT-2 selection screen
The converter is used at
1080P23SF; therefore, the
selection for OUT-2 becomes
either one of 1080P23PD or
1080P23SF.
Selecting 1080P23 is disabled.
ＦＲＡＭＥ ＲＡＴＥ ５９．９４Ｈｚ
１０８０Ｉ５９ ○
１０８０Ｐ２３ＰＤ ◎
１０８０Ｐ２９ＳＦ ○
１０８０Ｐ５９ ○
１０８０Ｉ５９ ○
１０８０Ｐ２３ＰＤ ○
１０８０Ｐ２９ＳＦ ○
ＳＹＳＴＥＭ ＦＯＲＭＡＴ
When SYSTEM FORMAT selects
1080P23PD format.
１０８０Ｐ２３ＰＤ ＹＣ ４２２ ＨＤ−ＳＤＩ ○
１０８０Ｐ２３ＳＦ ＹＣ ４２２ ＨＤ−ＳＤＩ ◎
１０８０Ｐ２３ ＹＣ ４２２ ＨＤ−ＳＤＩ ×
５２５Ｉ５９ ＳＤ−ＳＤＩ ○
ＯＵＴ−３
Selection for OUT-3 also becomes
either one of 1080P23PD or
1080P23SF.
(When SDTV option is
implemented, SD-SDI is select-
able.)
