BS-98 1409 VER1 (U) (E)
5.1 Settings from the BS Menu
AUDIO MANAGEMENT
AUDIO MANAGEMENT sets the audio output.
▲
ＳＹＳＴＥＭ ＦＯＲＭＡＴ
ＯＵＴＰＵＴ ＦＯＲＭＡＴ
ＲＥＴ ＶＩＤＥＯ ＦＯＲＭＡＴ
ＰＨＡＳＥ ＣＯＮＴＲＯＬ
ＭＩＣ ＭＡＮＡＧＥＭＥＮＴ
ＩＮＣＯＭ ＭＡＮＡＧＥＭＥＮＴ
▼
＊＊＊ ＥＮＧＩＮＥＥＲ（１／２） ＊＊＊
ＨＤ ＳＹＳ ＥＭＢＥＤＤＥＤ
ＨＤ ＯＵＴ−１ ＯＦＦ
ＨＤ ＯＵＴ−２ ＯＦＦ
ＨＤ ＯＵＴ−３ ＯＦＦ
ＨＤ ＰＭ ＯＦＦ
ＳＤ ＳＹＳ ＥＭＢＥＤＤＥＤ
ＳＤ ＳＤＩ ＯＦＦ
ＳＤ ＰＭ ＯＦＦ
ＭＩＣ ＭＡＮＡＧＥＭＥＮＴ
To position the flashing cursor on the "MIC
MANAGEMENT", and determine.
The submenu "MIC MANAGEMENT"
is displayed, on which you can perform
various settings.
Setting Item Set Value Description
HD SYS EMBEDDED ALL ON/OFF Sets whether to embed audio signal to all HDTV outputs.
HD OUT-1 ON/OFF Sets whether to embed audio signal to HDTV OUT-1 outputs.
HD OUT-2 ON/OFF Sets whether to embed audio signal to HDTV OUT-2 outputs.
HD OUT-3 ON/OFF Sets whether to embed audio signal to HDTV OUT-3 outputs.
HD PM ON/OFF Sets whether to embed audio signal to HDTV PM OUT outputs.
SD SYS EMBEDDED ALL ON/OFF Sets whether to embed audio signal to all SDTV outputs.
SD SDI ON/OFF Sets whether to embed audio signal to SDTV OUT-3 outputs.
SD PM ON/OFF Sets whether to embed audio signal to SDTV PM OUT outputs.
MASTER DELAY 0 to 21 It sets the audio signal delay amount of all systems.
HD SYS DELAY 0 to 21 It sets the audio signal delay amount of the HDTV system.
SD SYS DELAY 0 to 21 It sets the audio signal delay amount of the SDTV system.
DIGITAL DELAY 0 to 21 It sets the digital audio output delay amount.
MIC1/2 OUT DELAY 0 to 21 It sets the analog audio output delay amount.
MIC1 OUTPUT LEVEL 0dB/4dB It sets the MIC1 OUT output standard level (0 dB/4 dB).
MIC1 LVL ADJ (0dB) 1 to 1023 It sets the MIC1 OUT 0dB setting level.
MIC1 LVL ADJ (4dB) 1 to 1023 It sets the MIC1 OUT 4dB setting level.
MIC2 OUTPUT LEVEL 0dB/4dB It sets the MIC2 OUT output standard level (0 dB/4 dB).
MIC2 LVL ADJ (0dB) 1 to 1023 It sets the MIC2 OUT 0dB setting level.
MIC2 LVL ADJ (4dB) 1 to 1023 It sets the MIC2 OUT 4dB setting level.
MIC1 CENTER ADJ EXECUTE/CANCEL It adjusts the center OFFSET of the external MIC1 GAIN REMOTE control voltage.
MIC2 CENTER ADJ EXECUTE/CANCEL It adjusts the center OFFSET of the external MIC2 GAIN REMOTE control voltage.
・
MIC1/2 CENTER ADJ function
The microphone gain from the potentiometer connected to external system by the MIC GAIN REMOTE function to the camera
head can be changed continuously. However, there are cases that the mechanical and electrical center values and the control
voltage do not match depending on the potentiometer performance and features of each unit. In this case, the MAX/MIN control
amount becomes one-sided to the center value.
This function is to offset to the mechanical center position of the potentiometer to the center of the control value.
Generally, this setting is conducted at the factory, and adjustment is not required. If "CENTER ADJ" is executed at a wrong
position, the control range becomes abnormal. Pay close attention when adjusting.
