75
BS-98 1409 VER1 (U) (E)
5.1 Settings from the BS Menu
Setting Item Set Value Description
SD V PHASE 0 to 524 or
0 to 624
It adjusts the vertical phase of SDTV output signal to the external synchronization.
SD MASTER H PHASE -429 to 429 It adjusts the horizontal master phase of SDTV output signal to the external synchronization.
SD OUT-3 H PHASE -428 to 429 It adjusts the horizontal phase of SDTV OUT-3 output signal to the external synchronization.
SD SC PHASE COARSE -100 to 100 It coarse adjustment the subcarrier phase of SDTV output signal to the external
synchronization.
SD SC PHASE FINE -100 to 100 It coarse adjustment the subcarrier phase of SDTV output signal to the external
synchronization.
SD ENC H PHASE -428 to 429 It adjusts the horizontal phase of SDTV ENC output signal to the external synchronization.
SD PM H PHASE -428 to 429 It adjusts the horizontal phase of SDTV PM output signal to the external synchronization.
SYNC OUT H PHASE Changes
depending on
the FORMAT.
It adjusts the horizontal phase of the external synchronization output (SYNC OUT).
SYNC OUT V PHASE Changes
depending on
the FORMAT.
It adjusts the vertical phase of the external synchronization output (SYNC OUT).
・
SDTV output is optional. When an optional is not mounted, the phase adjusting item of SDTV displays "---", and selecting
becomes disabled.
