Ikegami BS-98 - Incom Management

77
BS-98 1409 VER1 (U) (E)
5.1 Settings from the BS Menu
INCOM MANAGEMENT
INCOM MANAGEMENT sets the intercom output.
▲
ＳＹＳＴＥＭ ＦＯＲＭＡＴ
ＯＵＴＰＵＴ ＦＯＲＭＡＴ
ＲＥＴ ＶＩＤＥＯ ＦＯＲＭＡＴ
ＰＨＡＳＥ ＣＯＮＴＲＯＬ
ＭＩＣ ＭＡＮＡＧＥＭＥＮＴ
ＩＮＣＯＭ ＭＡＮＡＧＥＭＥＮＴ
▼
＊＊＊ ＥＮＧＩＮＥＥＲ（１／２） ＊＊＊
ＥＮＧ Ｉ／Ｆ ４Ｗ
ＥＮＧ−ＩＮＰＵＴ ＴＥＲＭ ６００
ＥＮＧ−ＯＵＴＰＵＴ ＬＯＡＤ −−−
ＰＲＯＤ Ｉ／Ｆ ４Ｗ
ＰＲＯＤ−ＩＮＰＵＴ ＴＥＲＭ ６００
ＰＲＯＤ−ＯＵＴＰＵＴ ＬＯＡＤ −−−
ＥＮＧ−ＰＲＯＤ ２ＬＩＮＥ／１ＬＩＮＥ ２ＬＩＮＥ
ＦＲＯＮＴ ＩＮＣＯＭ ＤＹＮＡＭＩＣ
ＩＮＣＯＭ ＭＡＮＡＧＥＭＥＮＴ
To position the flashing cursor on the
"INCOM MANAGEMENT", and
determine.
The submenu "INCOM MANAGEMENT"
is displayed, on which you can perform
various settings.
Setting Item Set Value Description
ENG IF 4W It sets Engineer line intercom system in 4-wire.
RTS It sets Engineer line intercom system in RTS.
CC It sets Engineer line intercom system in Cler-Com.
ENG-INPUT TERM
(Valid only 4W setting)
600 It sets Input termination impedance of the Engineer line intercom system in 600

.
10k It sets Input termination impedance of the Engineer line intercom system in 10k

.
ENG-OUTPUT LOAD
(Valid only RTS/CC setting)
OPEN It sets system impedance setting of the Engineer line RTS/Cler-Com in OPEN.
200 It sets system impedance setting of the Engineer line RTS/Cler-Com in 200

.
PROD IF 4W It sets Producer line intercom system in 4-wire.
RTS It sets Producer line intercom system in RTS.
CC It sets Producer line intercom system in Cler-Com.
PROD-INPUT TERM
(Valid only 4W setting)
600 It sets Input termination impedance of the Producer line intercom system in 600

.
10k It sets Input termination impedance of the Producer line intercom system in 10k

.
PROD-OUTPUT LOAD
(Valid only RTS/CC setting)
OPEN It sets system impedance setting of the Producer line RTS/Cler-Com in OPEN.
200 It sets system impedance setting of the Producer line RTS/Cler-Com in 200

.
ENG-PROD 2LINE/1LINE 2LINE
This is the setting when the line system is used as individual two lines of Engineer/Producer.
1LINE Integrate Producer line to Engineer line to make them to one line.
FRONT INCOM DYNAMIC
It sets headset microphone to be connected to the front of the instrument in DYNAMIC type.
CARBON It sets headset microphone to be connected to the front of the instrument in CARBON type.
ECM It sets headset microphone to be connected to the front of the instrument in ECM type.
MIC POWER SUPPLY ON/OFF It sets whether or not the power is supplied when the microphone is set to EMC.
PGM1 TERM 600 It sets line termination impedance of the Program Audio #1 in 600

.
10k It sets line termination impedance of the Program Audio #1 in 10k

.
PGM1 INPUT LEVEL 4dB It sets input level of the Program Audio #1 in +4dBs.
0dB It sets input level of the Program Audio #1 in 0dBs.
-20dB It sets input level of the Program Audio #1 in -20dBs.
PGM2 TERM 600 It sets line termination impedance of the Program Audio #2 in 600

.
10k It sets line termination impedance of the Program Audio #2 in 10k

.
PGM2 INPUT LEVEL 4dB It sets input level of the Program Audio #2 in +4dBs.
0dB It sets input level of the Program Audio #2 in 0dBs.
-20dB It sets input level of the Program Audio #2 in -20dBs.
PGM3 TERM 600 It sets line termination impedance of the Program Audio #3 in 600

.
10k It sets line termination impedance of the Program Audio #3 in 10k

.
PGM3 INPUT LEVEL 4dB It sets input level of the Program Audio #3 in +4dBs.
0dB It sets input level of the Program Audio #3 in 0dBs.
-20dB It sets input level of the Program Audio #3 in -20dBs.
PGM MIX FRONT INCOM OFF/PGM1,2,3
It sets whether or not the PGM is mixed to the INCOM output at the HEADSET.
PGM -> FR-INCOM LEVEL x0.00 to 2.00 It sets level of PGM to mix in INCOM output at the HEADSET.
