4.6 External Connections
4.6 External Connections
■
CAMERA Connector
Used to connect the camera head to its CCU/BS.
Two types of CAMERA connector are available.
Name Function I/O ExternalInterface
OPTH-C/B
OPTC/B-H
Controlsignal(H)CCU/BS-->CameraCONTROL(H)
Controlsignal(C)Camera-->CCU/BSCONTROL(C)
Power(H)suppliedtothecameraPOWER(H)
Power(C)suppliedtothecameraPOWER(C)
○
○
○
○
○
○
1
2
3
4
5
6
LightcontactCamera-->CCU/BS
LightcontactCCU/BS-->Camera
IN
OUT
OUT
IN
OUT
OUT
PinNo.
Guidemark Guidemark
InsertionSide InsertionSide
[3KSeries] [OPSSeries]
――Receptacle―― ――Receptacle――
BSside:FFXW.3KorFCFRA BSside:OPS-PR
