4.6 External Connections
■
DATA TRK (DATA TRUNK)
This is the input/output connector for the serial communication standard RS-422.
InsertionSide
――Receptacle――
BSside :DE-9SF-T-N
Cableside:D-subconnector(9-pinmaleplugandinchscrews#4-40UNC)
PinNo. Name Function I/O ExternalInterface
N.C
TR1OUT(−) DigitalDataOutput(-)
DigitalDataInput(+)
InputShield
OutputShield
DigitalDataInput(-)
DigitalDataOutput(+)
GND
OUT
OUT
IN
IN
TR1IN(＋)
IN(S)
N.C
GND
OUT(S)
TR1OUT(＋)
TR1IN(−)
GND
○
○
○
○
○
○
1
2
3
4
5
6
○
○
○
7
8
9
