52
BS-98 1409 VER1 (U) (E)
4.6 External Connections
■
IF Connector
The serial communication standard RS-422 DATA TRUNK #2, Intercom external control, and preview switch contact are
assigned.
In DATA TRUNK #2, it is necessary for the camera head side to support.
InsertionSide
――Receptacle――
BSside :HR10A-10R-12SC(71)
Cableside:HR10A-10P-12PC(73) CrimpType
 :HR10A-10P-12P(73) Soldertype
PinNo. Name Function I/O ExternalInterface
DTATTRUNK2DigitalDataInput(+)
DTATTRUNK2DigitalDataOutput(+)
DTATTRUNK2Shield
CameraIncomMICOFFexternalcontrol
DTATTRUNK2DigitalDataInput(-)
DTATTRUNK2DigitalDataOutput(-)
PrivateIncomOFFexternalcontrol
HeadPowerONINDoutput
DC+12Vpoweroutput
Ground
Previewswitch
PreviewswitchGND
TR2IN(+)
TR2OUT(+)
TR2(S)
EXTMICOFF
TR2IN(-)
TR2OUT(-)
REMISOLATEOFF
HPIND
+12VOUT
GND
PREVIEWSW
PREVIEWCOM
IN
OUT
GND
IN
IN
OUT
IN
OUT
OUT
OUT
GND
1
2
3
4
5
6
7
8
9
10
11
12
